Operating weight

22000 kg

48502 lb

Engine power

124 kW (166 hp/168.6 ps) @ 2050 rpm

124 kW (166 hp/168.6 ps) @ 2050 rpm

Bucket capacity

1.0 / 1.1 / 1.2 m³

1.308/1.439/1.57 yd³

Maximum travel speed (High)

5.3 km/h

3 mph

Maximum travel speed (Low)

3.0 km/h

2 mph

Maximum swing speed

10.5 rpm

10.5 rpm

Arm breakout force

97 kN

21806 lbf

Arm breakout force Power boost

105 kN

23605 lbf

Bucket breakout force

140 kN

31473 lbf

Bucket breakout force Power boost

152.5 kN

34283 lbf

Shipping length

9570 mm

31'5"

Shipping width

2990 mm

9'10"

Shipping height

3140 mm

10'4"

Track shoe width (std)

600 mm

1'12"

Boom

5710 mm

18'9"

Arm

2915 mm

9'7"

Digging reach

9870 mm

32'5"

Digging reach on ground

9685 mm

31'9"

Digging depth

6562 mm

21'6"

Vertical wall digging depth

5080 mm

16'8"

Cutting height

9945 mm

32'8"

Dumping height

7170 mm

23'6"

Minimum front swing radius

3090 mm

10'2"

Model

Cummins QSB7

Cummins QSB7

Emission

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

System maximum flow

2×224 L/min (2x59 gal/min)

2×224 L/min (2x59 gal/min)

System pressure

34.3 MPa

4975 psi

Operating weight

23400 kg

51588 lb

Engine power

112 kW (150hp) @1950 rpm

112 kW (150hp) @1950 rpm

Bucket capacity

0.65 m³

0.85 yd³

Maximum travel speed (High)

5.3 km/h

3 mph

Track shoe width (std)

800 mm

2'7"

Boom

6680 mm

21'11"

Arm

4400 mm

14'5"

Digging reach

12050 mm

39'6"

Digging reach on ground

11900 mm

39'1"

Digging depth

8530 mm

27'12"

Vertical wall digging depth

7250 mm

23'9"

Cutting height

11625 mm

38'2"

Dumping height

9210 mm

30'3"

Minimum front swing radius

3550 mm

11'8"

Model

Cummins 6BTAA5.9-C150-Ⅱ

Cummins 6BTAA5.9-C150-Ⅱ

Emission

EPA Tier 2 / EU Stage II

EPA Tier 2 / EU Stage II

System maximum flow

2x224 L/min (2x59 gal/min)

2x224 L/min (2x59 gal/min)

System pressure

34.3 MPa

4975 psi

Operating weight

23850 kg

52580 lb

Engine power

112 kW (150 hp) @ 1950 rpm

112 kW (150 hp) @ 1950 rpm

Bucket capacity

0.45 m³

0.589 yd³

Maximum travel speed (High)

5.3 km/h

3 mph

Maximum travel speed (Low)

3.0 km/h

2 mph

Maximum swing speed

10.5 rpm

10.5 rpm

Arm breakout force Power boost

55 kN

12364 lbf

Bucket breakout force Power boost

70 kN

15737 lbf

Shipping length

12435 mm

40'10"

Shipping width

3190 mm

10'6"

Shipping height

3240 mm

10'8"

Track shoe width (std)

800 mm

2'7"

Boom

8500 mm

27'11"

Arm

6400 mm

20'12"

Digging reach

15110 mm

49'7"

Digging reach on ground

14985 mm

49'2"

Digging depth

11910 mm

39'1"

Vertical wall digging depth

9065 mm

29'9"

Cutting height

12780 mm

41'11"

Dumping height

10535 mm

34'7"

Minimum front swing radius

4270 mm

14'

Model

Cummins 6BTAA5.9-C150-II

Cummins 6BTAA5.9-C150-II

Emission

EPA Tier 2 / EU Stage II

EPA Tier 2 / EU Stage II

System maximum flow

2×224 L/min (2x59 gal/min)

2×224 L/min (2x59 gal/min)

System pressure

34.3 MPa

4975 psi

Operating weight

23400 kg

51588 lb

Engine power

124 kW (166 hp/160 ps) @ 2050 rpm

124 kW (166 hp/160 ps) @ 2050 rpm

Bucket capacity

0.65 m³

0.85 yd³

Maximum travel speed (High)

5.3 km/h

3 mph

Maximum swing speed

10.5 rpm

10.5 rpm

Track shoe width (std)

800 mm

2'7"

Boom

6680 mm

21'11"

Arm

4400 mm

14'5"

Digging reach

12050 mm

39'6"

Digging reach on ground

11900 mm

39'1"

Digging depth

8530 mm

27'12"

Vertical wall digging depth

7250 mm

23'9"

Cutting height

11625 mm

38'2"

Dumping height

9210 mm

30'3"

Minimum front swing radius

3550 mm

11'8"

Model

Cummins QSB7

Cummins QSB7

Emission

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

System maximum flow

2×224 L/min (2x59 gal/min)

2×224 L/min (2x59 gal/min)

System pressure

34.3 MPa

4975 psi

Operating weight

23850 kg

52580 lb

Engine power

124 kW (166 hp) @ 2050 rpm

124 kW (166 hp) @ 2050 rpm

Bucket capacity

0.45 m³

0.589 yd³

Maximum travel speed (High)

5.3 km/h

3 mph

Maximum travel speed (Low)

3.0 km/h

2 mph

Maximum swing speed

10.5 rpm

10.5 rpm

Arm breakout force Power boost

55 kN

12364 lbf

Bucket breakout force Power boost

70 kN

15737 lbf

Shipping length

12435 mm

40'10"

Shipping width

3190 mm

10'6"

Shipping height

3200 mm

10'6"

Track shoe width (std)

800 mm

2'7"

Boom

8500 mm

27'11"

Arm

6400 mm

20'12"

Digging reach

15110 mm

49'7"

Digging reach on ground

14985 mm

49'2"

Digging depth

11910 mm

39'1"

Vertical wall digging depth

9065 mm

29'9"

Cutting height

12780 mm

41'11"

Dumping height

10535 mm

34'7"

Minimum front swing radius

4270 mm

14'

Model

Cummins QSB7

Cummins QSB7

Emission

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

System maximum flow

2×224 L/min (2x59 gal/min)

2×224 L/min (2x59 gal/min)

System pressure

34.3 MPa

4975 psi
