Operating weight

16504 kg

36385 lb

Standard bucket

3.0 m³

3.9 yd³

Gross power

162 kW (220 hp) @ 2000 rpm

162 kW (220 hp) @ 2000 rpm

Net power

152 kW (202 hp) @ 2000 rpm

152 kW (202 hp) @ 2000 rpm

Rated load

5000 kg

11023 lb

Total cycle time

10.3 s

10.3 s

Tipping load-full turn

11100 kg

24471 lb

Bucket breakout force

161 kN

36194 lbf

Dump clearance, full height discharge

3037 mm

9'12"

Dump reach, full height discharge

1169 mm

3'10"

Model

Cummins 6LT9.3

Cummins 6LT9.3

Emissions

EPA Tier 2 / EU Stage II

EPA Tier 2 / EU Stage II

Cooling system

Charge air cooling

Charge air cooling

Length with bucket down

8106 mm

26'7"

Width over tires

2750 mm

9'

Cab height

3500 mm

11'6"

Turning radius, outside of tire

6086 mm

19'12"

Bucket capacity

2.7-4 m³

3.5-5.2 yd³

General Purpose

3.0 m³

3.9 yd³

Light material

4.2, 4.7, 5.2 m³

4.2, 4.7, 5.2 yd³
