Operating weight

15510 kg

34194 lb

Standard bucket

2.7 m³

3.5 yd³

Maximum gross power

136 kW (185 hp) @ 2100 rpm

136 kW (185 hp) @ 2100 rpm

Maximum net power

129kW ( 175 hp) @ 2100 rpm

129kW ( 175 hp) @ 2100 rpm

Rated load

4800 kg

10582 lb

Total cycle time

10.1 s

10.1 s

Tipping load-full turn

10220 kg

22531 lb

Bucket breakout force

117 kN

26303 lbf

Dump clearance, full height discharge

2775 mm

9'1"

Dump reach, full height discharge

1099 mm

3'7"

Model

Cummins QSB6.7

Cummins QSB6.7

Emissions

EPA Tier 4F / EU Stage IV

EPA Tier 4F / EU Stage IV

Cooling system

Charge air cooling

Charge air cooling

Length with bucket down

7757 mm

25'5"

Width over tires

2548 mm

8'4"

Cab height

3310 mm

10'10"

Turning radius, outside of tire

5590 mm

18'4"

Bucket capacity

2.5-4.5 m³

3.3-5.9 yd³

General Purpose

2.7 m³

3.5 yd³

Light material

3.0, 3.5, 4.5 m³

3.0, 3.5, 4.5 yd³

Heavy-rock

1.8 m³

2.4 yd³
