Wheel Loaders835H

Product Features

Specifications

835H-Stage-II

835H－835H (Stage II)

Operating weight

10075 kg

Standard bucket

1.8 m³

Gross power

92 kW (125 hp) @ 2000 rpm

Net power

85 kW (116 hp) @ 2000 rpm

Rated load

3000 kg

Total cycle time

9.7 s

Tipping load-full turn

6700 kg

Bucket breakout force

99 kN

Dump clearance, full height discharge

2938 mm

Dump reach, full height discharge

1042 mm

Model

Weichai WP6G125E221

Emissions

EPA Tier 2 / EU Stage II

Cooling system

Charge air cooling

Length with bucket down

7193 mm

Width over tires

2295 mm

Cab height

3340 mm

Turning radius, outside of tire

5090 mm

Bucket capacity

1.5-3.2 m³

General Purpose

1.8 m³

Light material

2.5, 3.0 m³

Heavy-rock

1.5 m³

Connect Dealer

835H-Stage-IV---Tier-4F

835H－835H (Stage IV / Tier 4F)

Operating weight

11160 kg

Standard bucket

1.9 m³

Maximum gross power

98 kW (133 hp) @ 2200 rpm

Maximum net power

93 kW (126 hp) @ 2200 rpm

Rated load

3300 kg

Total cycle time

9.7 s

Tipping load-full turn

6600 kg

Bucket breakout force

83 kN

Dump clearance, full height discharge

2602 mm

Dump reach, full height discharge

1144 mm

Model

Perkins 1204F-E44TAN

Emissions

EPA Tier 4F / EU Stage IV

Cooling system

Charge air cooling

Length with bucket down

7124 mm

Width over tires

2300 mm

Cab height

3200 mm

Turning radius, outside of tire

5410 mm

Bucket capacity

1.5-3.0 m³

General Purpose

1.9 m³

Light material

2.5, 3.0 m³

Heavy-rock

1.5 m³
