Wall width

0.8-1.5 m

3-5 ft

Wall depth

80 m

262 ft

Output torque of trench cutter

120×2 kN·m

88507×1475 lbf/ft

Rotation speed Max of trench cutter

0-25 rpm

0-25 rpm

Pull force of winch

2×350 kN

450×78683 lbf

System pressure

33 MPa

4786 psi

Main pump flow

2×380+130+330 L/min

1×100+34+87 gal/min

Weight of Cutter Wheel

40(B=1500) t

40(B=1500) lb

Total Weight ( w/o cutter wheel )

98 t

216053 lb

Diesel

Cummins QSM11

Cummins QSM11

Power Rotation speed

300@1900 rpm

300@1900 rpm

Electric moter

Y315S+Y225M

Y315S+Y225M

Power

110+45 kW

147+60 hp

Model of undercarriage

SH36-R455LC-7 JT90

SH36-R455LC-7 JT90

Track shoe outer distance

3450-4600 mm

11'4"-15'1"

Track shoes width

800 mm

2'7"

Towing force

630 kN

141630 lbf

Crawler speed

1.5 km/h

1 mph
