Engine Power

70 kW (95 hp) @ 2300 rpm

70 kW (95 hp) @ 2300 rpm

Operating Weight

3850 kg

8488 lb

Rated Operation Capacity

1133 kg

2498 lb

Raise

3.54 s

3.54 s

Dump

2.52 s

2.52 s

Lower (empty, float down)

2.08 s

2.08 s

Tipping Load

2267 kg

4998 lb

Bucket Breakout Force

32.63 kN

7336 lbf

Dump Clearance - Full Height

2572 mm

8'5"

Dump Reach - Full Height

587 mm

1'11"

Engine Model

Perkins 1104D-44T

Perkins 1104D-44T

Emission

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

Cooling System

20 L

5 gal

Overall Length with Standard Bucket

3851 mm

12'8"

Overall Width with Standard Bucket

1850 mm

6'1"

Overall Height to top of Cab

2034 mm

6'8"

Front Clearance Radius with bucket

2324 mm

7'7"

Bucket capacity

0.55 m³

0.7 yd³
