Skid Steer Loaders385B

  • Metric
  • U.S.

Product Features

Specifications

385B-Stage-III

385B－385B Stage III

Engine Power

61.3 kW (83.3hp) @ 2400 rpm

Operating Weight

3750 kg

Rated Operation Capacity

1045 kg

Raise

4.2 s

Dump

2.8 s

Lower (empty, float down)

2.5 s

Tipping Load

2090 kg

Bucket Breakout Force

29.8 kN

Dump Clearance - Full Height

2572 mm

Dump Reach - Full Height

587 mm

Engine Model

Yanmar 4TNV98T-ZCNLYSC

Emission

EPA Tier 3 / EU Stage IIIA

Cooling System

20 L

Overall Length with Standard Bucket

3851 mm

Overall Width with Standard Bucket

1850 mm

Overall Height to top of Cab

2034 mm

Front Clearance Radius with bucket

2339 mm

Bucket capacity

0.5 m³

375B_385B-IV-12-Pg-A4-Broch.pdf

385B-Stage-IV

385B－385B Stage IV

Engine Power

53.7 kW (73 hp) @ 2400 rpm

Operating Weight

3750 kg

Rated Operation Capacity

1045 kg

Raise

3.66 s

Dump

2.82 s

Lower (empty, float down)

1.79 s

Tipping Load

2090 kg

Bucket Breakout Force

29.8 kN

Dump Clearance - Full Height

2572 mm

Dump Reach - Full Height

587 mm

Engine Model

Yanmar 4NV98CT-NLYS

Emission

EPA Tier 4F / EU Stage IIIB

Cooling System

20 L

Overall Length with Standard Bucket

3851 mm

Overall Width with Standard Bucket

1850 mm

Overall Height to top of Cab

2034 mm

Front Clearance Radius with bucket

2324 mm

Bucket capacity

0.5 m³

SSL-375B_385B-T4-12-Pg-A4-Broch_03_2019.pdf
