Engine Power

50.3 kW (67.4 hp) @ 2400 rpm

50.3 kW (67.4 hp) @ 2400 rpm

Operating Weight

3100 kg

6834 lb

Rated Operation Capacity

865 kg

1907 lb

Raise

4.2 s

4.2 s

Dump

2.3 s

2.3 s

Lower (empty, float down)

2.1 s

2.1 s

Tipping Load

1730 kg

3814 lb

Bucket Breakout Force

20.4 kN

4586 lbf

Dump Clearance - Full Height

2220 mm

7'3"

Dump Reach - Full Height

540 mm

1'9"

Engine Model

Yanmar 4TNV98-ZPLYS

Yanmar 4TNV98-ZPLYS

Emission

EU Stage Ⅲ

EU Stage Ⅲ

Cooling System

13 L

3 gal

Overall Length with Standard Bucket

3432 mm

11'3"

Overall Width with Standard Bucket

1630 mm

5'4"

Overall Height to top of Cab

1940 mm

6'4"

Front Clearance Radius with bucket

1800 mm

5'11"

Bucket capacity

0.45 m³

0.6 yd³

Engine Power

50 kW (68 hp) @ 2400 rpm

50 kW (68 hp) @ 2400 rpm

Operating Weight

3100 kg

6834 lb

Rated Operation Capacity

865 kg

1907 lb

Raise

4.2 s

4.2 s

Dump

2.3 s

2.3 s

Lower (empty, float down)

2.1 s

2.1 s

Tipping Load

1730 kg

3814 lb

Bucket Breakout Force

20.8 kN

4676 lbf

Dump Clearance - Full Height

2220 mm

7'3"

Dump Reach - Full Height

540 mm

1'9"

Engine Model

Yanmar 4TNV98C-ZPLYS

Yanmar 4TNV98C-ZPLYS

Emission

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

Cooling System

13 L

3 gal

Overall Length with Standard Bucket

3432 mm

11'3"

Overall Width with Standard Bucket

1630 mm

5'4"

Overall Height to top of Cab

1940 mm

6'4"

Front Clearance Radius with bucket

1800 mm

5'11"

Bucket capacity

0.4 m³

0.5 yd³
