Engine Power

35.7 kW (48.5 hp) @ 2600 rpm

35.7 kW (48.5 hp) @ 2600 rpm

Operating Weight

2950 kg

6504 lb

Rated Operation Capacity

795 kg

1753 lb

Raise

3.9 s

3.9 s

Dump

1.9 s

1.9 s

Lower (empty, float down)

2.1 s

2.1 s

Tipping Load

1590 kg

3505 lb

Bucket Breakout Force

20.8 kN

4676 lbf

Dump Clearance - Full Height

2220 mm

7'3"

Dump Reach - Full Height

540 mm

1'9"

Engine Model

Perkins 404D-22

Perkins 404D-22

Emission

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

Cooling System

13 L

3 gal

Overall Length with Standard Bucket

3432 mm

11'3"

Overall Width with Standard Bucket

1630 mm

5'4"

Overall Height to top of Cab

1940 mm

6'4"

Front Clearance Radius with bucket

1800 mm

5'11"

Bucket capacity

0.4 m³

0.5 yd³
