Operating Mass

19000 kg

41888 lb

Mass On Vibrating Drum

9500 kg

20944 lb

Mass On Drive Axle

9500 kg

20944 lb

Front Drum Static Linear Load

446 N/cm

39 lbf/inch

Model

Shangchai SC7H210.1G2

Shangchai SC7H210.1G2

Emission Regulation

Stage II

Stage II

Rated Power

155 kW (208 hp / 211 ps) @ 2,000 rpm

155 kW (208 hp / 211 ps) @ 2,000 rpm

Vibration Frequency

28 / 32 Hz

28 / 32 Hz

Nominal Amplitude

2.0 / 1.3 mm

/

Centrifugal Force

360/300 kN

80931/67443 lbf

Drum Diameter

1600 mm

5'3"

1st Maximum Speed, fwd

2.7 km/h

2 mph

2nd Maximum Speed, fwd

5.2 km/h

3 mph

3rd Maximum Speed, fwd

11 km/h

7 mph

Theoretical Gradeability

30%

30%

Min. GroundClearance

450 mm

1'6"

Wheelbase

3230 mm

10'7"

Min. Outside Turning Radius

7000 mm

22'12"

Overall Length

6450 mm

21'2"

Overall Width

2340 mm

7'8"

Overall Height

3150 mm

10'4"
