Operating Mass

16000 kg

35274 lb

Mass On Vibrating Drum

8000 kg

17637 lb

Mass On Drive Axle

8000 kg

17637 lb

Front Drum Static Linear Load

368 N/cm

33 lbf/inch

Model

Shangchai SC4H140.2G2

Shangchai SC4H140.2G2

Emission Regulation

Stage II

Stage II

Rated Power

103 kW (140 hp) @ 2000 rpm

103 kW (140 hp) @ 2000 rpm

Vibration Frequency

30 Hz

30 Hz

Nominal Amplitude

2.0/1.2 mm

/

Centrifugal Force

300/180 kN

67443/40466 lbf

Drum Diameter

1555 mm

5'1"

1st Maximum Speed, fwd

2.7 km/h

2 mph

2nd Maximum Speed, fwd

5.2 km/h

3 mph

3rd Maximum Speed, fwd

11 km/h

7 mph

Theoretical Gradeability

30%

30%

Min. GroundClearance

450 mm

1'6"

Wheelbase

2950 mm

9'8"

Min. Outside Turning Radius

6500 mm

21'4"

Overall Length

6000 mm

19'8"

Overall Width

2280 mm

7'6"

Overall Height

3050 mm

10'
