Paving Width Range

2.5～9.5 m

2.5～9.5 ft

Maximum Paving Thickness

350 mm

1'2"

Theoretical Productivity

800 t/h

1763698 lb/h

Operating Mass

22 t

48502 lb

Model

QSB6.7-215C

QSB6.7-215C

Rated Power

158 kW (215 hp) @ 2000 rpm

158 kW (215 hp) @ 2000 rpm

Paving Speed

0～18 m/min

0～18 ft/min

Traveling Speed

0～2.8 km/h

0～2.8 mph

Hopper Capacity

16 t

35274 lb

Gradability

≥20%

≥20%

Smoothness

≤2 mm

≤

Slope Error

±0.02%

±0.02%

Tamper Type

Double Tamper

Double Tamper

Tamper Frequency

0～25

0～25

Tamper Swing Front

0/3/6/8.5/12 mm

////

Tamper Swing Rear

3/5/6/7/8/9 mm

/////

Vibration Frequency

1-50

1-50

Crown Adjustment

-1~3%

-1~3%

Paving Compactness Asphalt Asphalt

≥90%

≥90%

Paving Compactness Asphalt Stabilized Soil

≥80%

≥80%

Fuel Tank Capacity

330 L

87 gal

Length

6923 mm

22'9"

Width

2720 mm

8'11"

Height

3808 mm

12'6"
