Working height

24600 mm

80'9"

Weight ( without drilling tools)

87000 kg

191802 lb

Upper chassis

JS80

JS80

Engine

QSM11-Tier3

QSM11-Tier3

Rated Power

299/1900

299/1900

Hydraulic system flow

2×380+152 L/min

1×100+151 gal/min

Hydraulic system pressure

33 MPa

4786 psi

Fuel tank capacity

650 L

172 gal

Hydraulic tank capacity

420 L

111 gal

Extendable under carriage

JT80

JT80

Shoes width

800 mm

2'7"

Chassis length

5680 mm

18'8"

Undercarriage width

3300-4400 mm

10'10"-14'5"

Traction force

500 kN

112404 lbf

Travelling speed

1.5 km/h

1 mph

Rotary torque

300 kN·m

221269 lbf/ft

Rotation speed

6-30 r/min

6-30

Single line pull of Main winch

300 kN

67443 lbf

Rope dia of Main winch

36 mm

1"

Max lifting speed of Main winch

65 m/min

213 ft/min

Single line pull of Auxiliary winch

75 kN

16861 lbf

Rope Dia of Auxiliary winch

18 mm

1"

Maximum lifting speed of Auxiliary winch

45 m/min

148 ft/min

Stroke

5700 mm

18'8"

Crowd force

250 kN

56202 lbf

Pulling force

250 kN

56202 lbf

Standard max stroke

10000 mm

32'10"

Crowd force

250 kN

56202 lbf

Pulling force

250 kN

56202 lbf
