Operating weight

19500 kg

42990 lb

Weight on front wheels

5850 kg

12897 lb

Weight on rear tandem

13650 kg

30093 lb

Drawbar pull

100 kN

22481 lbf

Model

Cummins 6LTAA8.9-C240

Cummins 6LTAA8.9-C240

Emission regulation

Tier 2 / Stage II

Tier 2 / Stage II

Rated power

179 kW (243 hp) @ 2200 rpm

179 kW (243 hp) @ 2200 rpm

Net power

162 kW (220 hp) @ 2200 rpm

162 kW (220 hp) @ 2200 rpm

Type

Power shift

Power shift

Speeds

6f / 3r

6f / 3r

Maximum travel speed, forward

36.6 km/h

23 mph

Maximum travel speed, reverse

23 km/h

14 mph

Turning radius

8000 mm

26'3"

Articulation angle

±20°

±20°

Maximum overall height

3460 mm

11'4"

Width over tires

2915 mm

9'7"

Blade width

4572 mm

15'

Overall length

9570 mm

31'5"
