Operating weight

15500 kg

34172 lb

Weight on front wheels

4650 kg

10251 lb

Weight on rear tandem

10850 kg

23920 lb

Drawbar pull

86 kN

19334 lbf

Model

Cummins 6BTAA5.9-C190

Cummins 6BTAA5.9-C190

Emission regulation

Tier 2 / Stage II

Tier 2 / Stage II

Rated power

142 kW (190 hp) @ 2200 rpm

142 kW (190 hp) @ 2200 rpm

Net power

115 kW (172 hp) @ 2200 rpm

115 kW (172 hp) @ 2200 rpm

Type

Power shift

Power shift

Speeds

6f / 3r

6f / 3r

Maximum travel speed, forward

42 km/h

26 mph

Maximum travel speed, reverse

26.2 km/h

16 mph

Turning radius

7200 mm

23'7"

Articulation angle

±27º

±27º

Maximum overall height

3380 mm

11'1"

Width over tires

2600 mm

8'6"

Blade width

3960 mm

12'12"

Overall length

9090 mm

29'10"
