Operating weight

5900 kg

13007 lb

Engine power

36.2 kW (48.5 hp) @ 2100 rpm

36.2 kW (48.5 hp) @ 2100 rpm

Bucket capacity

0.06-0.23 m³

0.078-0.301 yd³

Maximum travel speed (High)

4.1 km/h

3 mph

Maximum travel speed (Low)

2.5 km/h

2 mph

Maximum swing speed

10.4 rpm

10.4 rpm

Arm breakout force

31 kN

6969 lbf

Bucket breakout force

41 kN

9217 lbf

Shipping length

5900 mm

19'4"

Shipping width

1900 mm

6'3"

Shipping height

2630 mm

8'8"

Track shoe width (std)

400 mm

1'4"

Boom

3000 mm

9'10"

Arm

1600 mm

5'3"

Digging reach

6205 mm

20'4"

Digging reach on ground

6065 mm

19'11"

Digging depth

3875 mm

12'9"

Vertical wall digging depth

2940 mm

9'8"

Cutting height

5790 mm

18'12"

Dumping height

4135 mm

13'7"

Minimum front swing radius

2430 mm

7'12"

Dozer-up

360 mm

1'2"

Dozer-down

405 mm

1'4"

Model

Yanmar 4TNV94L-BVLY

Yanmar 4TNV94L-BVLY

Emission

EU Stage IIIA / Tier 4i

EU Stage IIIA / Tier 4i

System maximum flow

142.8 L/min (37.7 gal/min)

142.8 L/min (37.7 gal/min)

System pressure

25 MPa

3626 psi
