Operating weight

1750 kg

3858 lb

Engine power

11.8 kW @ 2,300 rpm

11.8 kW @ 2,300 rpm

Bucket capacity

0.045 m³

0.059 yd³

Maximum travel speed (High)

4.0 km/h

2 mph

Maximum travel speed (Low)

2.2 km/h

1 mph

Maximum swing speed

9.5 rpm

9.5 rpm

Arm breakout force

9 kN

2023 lbf

Bucket breakout force

16 kN

3597 lbf

Shipping length

2410 mm

7'11"

Shipping width

980 mm

3'3"

Shipping height

2410 mm

7'11"

Track shoe width (std)

230 mm

9"

Boom

1685 mm

5'6"

Arm

1070 mm

3'6"

Digging reach

3910 mm

12'10"

Digging reach on ground

3840 mm

12'7"

Digging depth

2255 mm

7'5"

Vertical wall digging depth

1780 mm

5'10"

Cutting height

3420 mm

11'3"

Dumping height

2400 mm

7'10"

Minimum front swing radius

645 mm

2'1"

Model

Kubota D902

Kubota D902

Emission

EU Stage V / Tier 4F

EU Stage V / Tier 4F

System maximum flow

44 L/min ( 11.6 gal/min)

44 L/min ( 11.6 gal/min)
