Borehole Diameter

76-127 mm

3"-5"

Pipe Sizes

T45,T51 mm

T45,T51

Length

9200 mm

30'2"

Width

2350 mm

7'9"

Height

3100 mm

10'2"

Weight

12500 kg

27558 lb

Value List

330 mm

1'1"

Track Oscillation

30/12 °

30/12 °

Max Walking Speed

4.3/2.8 km/h

3/2 mph

Ground Clearance

420 mm

1'5"

Track Oscillation

±10 °

±10 °

Motor Speed

3300 rpm

3300 rpm

Filter Area

15 ㎡

15 ㎡

Supplier

Sullivan-Palatek

Sullivan-Palatek

FAD

10.5 m³/s

22248 CFM

Discharge Pressure

10.5 bar

10.5 bar

Model

QSC8.3-260 III

QSC8.3-260 III

Rated Power

194 kW

260 hp

Fuel Tank Capacity

400 L

106 gal

Feeding Stroke

4420 mm

14'6"

Feeding Force

16 kN

3597 lbf

Lifting Force

21 kN

4721 lbf

Model

YH-100

YH-100

Percussive Power

20.6 kW

28 hp

Percussive Frequency

2500 Bpm

2500 Bpm

Turning Speed

0-150 rpm

0-150 rpm

Boom Tilt Angle

55 up/30 down °

55 up/30 down °

Boom Swing Angle

60 Left/40 Right °

60 Left/40 Right °

Skates Swing Angle

50 Left/40 Right °

50 Left/40 Right °
