Borehole Diameter

115-185 mm

5"-7"

Pipe Sizes

64/76/89x3000 mm

3"/3"/4"x9'10"

Hammer Size

3''/4''/5''/6''

3''/4''/5''/6''

Max Rotation Speed

70 rpm

70 rpm

Max Rotation Torque

3680 N·m

2714 lbf/ft

Feeding Stroke

3750 mm

12'4"

Feed Extension

1260 mm

4'2"

Feed Speed

0.59 m/s

2 ft/s

Feed Force

12 kN

2698 lbf

Pull Up Force

30 kN

6744 lbf

Length of Feed Beam

6300 mm

20'8"

Max Walking Speed

3 km/h

2 mph

Track Oscillation

±13 °

±13 °

Ground Clearance

320 mm

1'1"

Grad Ability

32 °

32 °

Rated Power

73.5/75 kW

99/101 hp

Engine

YuChai/WeiChai

YuChai/WeiChai

Length

6500 mm

21'4"

Width

2310 mm

7'7"

Height

2450 mm

8'

Weight

6800 kg

14991 lb
