Borehole Diameter

115-152 mm

5"-6"

Pipe Sizes

76/89x3000 mm

3"/4"x9'10"

Hammer Size

4''/5''

4''/5''

Max Rotation Speed

100 rpm

100 rpm

Max Rotation Torque

3000 N·m

2213 lbf/ft

Feeding Stroke

3000 mm

9'10"

Feed Extension

1200 mm

3'11"

Feed Speed

0.59 m/s

2 ft/s

Feed Force

15 kN

3372 lbf

Pull Up Force

25 kN

5620 lbf

Length of Feed Beam

5500 mm

18'1"

Max Walking Speed

2 km/h

1 mph

Track Oscillation

±10 °

±10 °

Ground Clearance

320 mm

1'1"

Grad Ability

30 °

30 °

Rated Power

59 kW

79 hp

Engine

YuChai

YuChai

Length

5400 mm

17'9"

Width

2330 mm

7'8"

Height

2020 mm

6'8"

Weight

7000 kg

15432 lb
