Max. rated lifting capacity

30 t

66139 lb

Max. rated lifting torque of basic boom

1040 kN·m

767064 lbf/ft

Max. rated lifting torque of full extended

596 kN·m

439587 lbf/ft

Max. lifting height of main boom

34 m

112 ft

Max. lifting height of Jib

34+8.7 m

112+29 ft

Overall net weight

30000 kg

66139 lb

Max. single rope speed

130 m/min

427 ft/min

Time of telescoping boom

55 s

55 s

Time of elevating boom

35

35

Max. slewing speed

2.4 rpm

2.4 rpm

Max. travel speed

80 km/h

50 mph

Gradeability

40%

40%

Min. turning diameter

≤24 m

≤79 ft

Dimensions (L x W x H)

12790x2600x3400 mm

41'12"x8'6"x11'2"

Outrigger longitudinal span

5430 mm

17'10"

Outrigger transverse span

6400 mm

20'12"

Sections of boom

4

4

Length of main boom

34 m

112 ft

Length of jib

8.8 m

29 ft

Engine Model

ISDe 285 30

ISDe 285 30

Rated power

210 kW

282 hp

Max. rated torque

970 N·m

715 lbf/ft
