Max. rated lifting capacity

25 t

55116 lb

Max. rated lifting torque of basic boom

1120 kN·m

826069 lbf/ft

Max. rated lifting torque of full extended

608 kN·m

448438 lbf/ft

Max. lifting height of main boom

41 m

135 ft

Max. lifting height of Jib

41+8.8 m

135+29 ft

Overall net weight

32700 kg

72091 lb

Max. single rope speed

130 m/min

427 ft/min

Time of telescoping boom

78 s

78 s

Time of elevating boom

35

35

Max. slewing speed

2.4 rpm

2.4 rpm

Max. travel speed

80 km/h

50 mph

Gradeability

40%

40%

Min. turning diameter

20 m

66 ft

Dimensions (L x W x H)

12760x2490x3500 mm

41'10"x8'2"x11'6"

Outrigger longitudinal span

5600 mm

18'4"

Outrigger transverse span

6200 mm

20'4"

Sections of boom

5

5

Length of main boom

41 m

135 ft

Length of jib

8.8 m

29 ft

Engine Model

ISDe 285 30

ISDe 285 30

Rated power

210 kW

282 hp

Max. rated torque

970 N·m

715 lbf/ft
