Max. rated lifting capacity

25 t

55116 lb

Max. rated lifting torque of basic boom

1083 kN·m

798780 lbf/ft

Max. rated lifting torque of full extended

592 kN·m

436637 lbf/ft

Max. lifting height of main boom

34 m

112 ft

Max. lifting height of Jib

34+8.7 m

112+29 ft

Overall net weight

30400 kg

67021 lb

Max. single rope speed

130 m/min

427 ft/min

Time of telescoping boom

55 s

55 s

Time of elevating boom

45(35)

45(35)

Max. slewing speed

2.4 rpm

2.4 rpm

Max. travel speed

80 km/h

50 mph

Gradeability

40%

40%

Min. turning diameter

20 m

66 ft

Dimensions (L x W x H)

12850x2490x3460 mm

42'2"x8'2"x11'4"

Outrigger longitudinal span

5600 mm

18'4"

Outrigger transverse span

6200 mm

20'4"

Sections of boom

4

4

Length of main boom

34 m

112 ft

Length of jib

8.8 m

29 ft

Engine Model

ISDe 285 30

ISDe 285 30

Rated power

210 kW

282 hp

Max. rated torque

970 N·m

715 lbf/ft
