Operating weight

8700 kg

19180 lb

Engine power

46.2 kW (62.0 hp) @ 2200 rpm

46.2 kW (62.0 hp) @ 2200 rpm

Bucket capacity

0.23-0.32 m³

0.301-0.419 yd³

Maximum travel speed (High)

4.8 km/h

3 mph

Maximum travel speed (Low)

2.4 km/h

1 mph

Maximum swing speed

10.5 rpm

10.5 rpm

Arm breakout force

43 / 37 kN

9667/8318 lbf

Bucket breakout force

63 kN

14163 lbf

Shipping length

6460 mm

21'2"

Shipping width

2200/2400 mm

7'3"/7'10"

Shipping height

2710 mm

8'11"

Track shoe width (std)

450 mm

1'6"

Boom

3375 mm

11'1"

Arm

1650 / 2100 mm

5'5"/6'11"

Digging reach

6847 / 7264 mm

22'6"/23'10"

Digging reach on ground

6651 / 7082 mm

21'10"/23'3"

Digging depth

4093 / 4540 mm

13'5"/14'11"

Vertical wall digging depth

3043 / 3963 mm

9'12"/13'

Cutting height

6300/ 6525 mm

20'8"/21'5"

Dumping height

4352/ 4577 mm

14'3"/15'

Minimum front swing radius

2421 mm

7'11"

Dozer-up

440 mm

1'5"

Dozer-down

420 mm

1'5"

Swing boom left rotation

65 °

65 °

Swing boom right rotation

55 °

55 °

Model

Yanmar 4TNV98C-SLY

Yanmar 4TNV98C-SLY

Emission

EU Stage IIIB / EPA Tier 4F

EU Stage IIIB / EPA Tier 4F

System maximum flow

196 L/min ( 52 gal/min)

196 L/min ( 52 gal/min)

System pressure

28 MPa

4061 psi
