Operating weight

14500 kg

31967 lb

Milling width

1000 mm

3'3"

Milling depth

0-180 mm

0-0.7 inch

D No. of tools

92

92

Model

Cummins QSB5.9-C210

Cummins QSB5.9-C210

Rated power

154 kW (209 hp) @ 2200 rpm

154 kW (209 hp) @ 2200 rpm

Emission

China III

China III

Travel speed

0-8 km/h

0-4.97 mph

Operating speed

0-30 km/h

0-18.64 mph

Gradeability

100%

100%

Fuel

370 L

98 gal

Hydraulic oil

120 L

32 gal

Water tank

920 L

243 gal

Shipping Length

8200 mm

26'11"

Shipping width

2460 mm

8'1"

Shipping height

2850 mm

9'4"
