Gross Power

74.5 kW (101 hp) @ 2200 rpm

74.5 kW (101 hp) @ 2200 rpm

Net Power

72 kW (98 hp) @ 2200 rpm

72 kW (98 hp) @ 2200 rpm

Operating Weight

8400 kg

18519 lb

Maximum Digging Depth

4440 mm

14'7"

Maximum speed

5.9 - 36 km/h

4-22 mph

Turning Radius Outside of Front Tire w/o single braking

4400 mm

14'5"

Turning Radius Outside of Bucket w/o single braking

5554 mm

18'3"

Turning Radius Outside of Front Tire w/ single braking

3450 mm

11'4"

Bucket Breakout Force, General bucket

60.1 kN

13511 lbf

Bucket Digging Force

58.2 kN

13084 lbf

Maximum Dump Height (Loading)

2691 mm

8'10"

Loading Height (Digging)

3586 mm

11'9"

Model

Perkins 1104D-44TA

Perkins 1104D-44TA

Emission Standard

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

Standard Bucket Heaped Capacity

1 m³

1.3 yd³

Standard Backhoe Bucket Heaped Capacity

0.2 m³

0.3 yd³
