Gross Power

74.5 kW (102 hp) @ 2200 rpm

74.5 kW (102 hp) @ 2200 rpm

Net Power

72 kW (98 hp) @ 2200 rpm

72 kW (98 hp) @ 2200 rpm

Operating Weight

9480 kg

20900 lb

Maximum Digging Depth

4345 mm

14'3"

Maximum speed

6.6 - 41 km/h

4-25 mph

Turning Radius Outside of Front Tire w/o single braking

4950 mm

16'3"

Turning Radius Outside of Bucket w/o single braking

5200 mm

17'1"

Bucket Breakout Force, General bucket

59.6 kN

13399 lbf

Bucket Digging Force

58.2 kN

13084 lbf

Maximum Dump Height (Loading)

2746 mm

9'

Loading Height (Digging)

3586 mm

11'9"

Model

Perkins 1104D-44TA

Perkins 1104D-44TA

Emission Standard

EPA Tier 3 / EU Stage IIIA

EPA Tier 3 / EU Stage IIIA

Standard Bucket Heaped Capacity

1.1 m³

1.4 yd³

Standard Backhoe Bucket Heaped Capacity

0.22 m³

0.3 yd³
