Gross Power

75 kW (102 hp) @ 2200 rpm

75 kW (102 hp) @ 2200 rpm

Net Power

72 kW (98 hp) @ 2200 rpm

72 kW (98 hp) @ 2200 rpm

Operating Weight

8600 kg

18960 lb

Maximum Digging Depth

4440 mm

14'7"

Maximum speed

9.8 - 44 km/h

6-27 mph

Turning Radius Outside of Front Tire w/o single braking

4800 mm

15'9"

Turning Radius Outside of Bucket w/o single braking

/ mm

/

Turning Radius Outside of Front Tire w/ single braking

/ mm

/

Bucket Breakout Force, General bucket

52.1 kN

11713 lbf

Bucket Digging Force

52.1 kN

11713 lbf

Maximum Dump Height (Loading)

2691 mm

8'10"

Loading Height (Digging)

3586 mm

11'9"

Model

Yuchai YC4A105Z-T20

Yuchai YC4A105Z-T20

Emission Standard

EPA Tier 2 / EU Stage II

EPA Tier 2 / EU Stage II

Standard Bucket Heaped Capacity

1 m³

1.3 yd³

Standard Backhoe Bucket Heaped Capacity

0.2 m³

0.3 yd³
